Complete Swisher ZTR2766BS 66-inch Mower Specs
12
V
Battery
66
-inch
cutting width
| Under The Hood | |
|---|---|
| Engine Make | Briggs & Stratton |
| Engine ignition | Switch |
| Engine cylinders | 2 |
| Engine cooling | Air |
| Engine fuel | Gasoline |
| Fuel Tank Capacity (quarts) | 32 |
| Fuel Tank Capacity (litres) | 30.28 |
| Engine lubrication type | SAE 20w-50 |
| Oli filter |  |
| Fan-cooled pumps | |
| Battery | Lead-acid |
| Battery voltage | 12 V |
| Engine power Kw | 36.2 |
| Horsepower | 27 HP |
| Mowing Features | |
| Cutting width (inches) | 66 |
| Cutting deck type | Welded steel |
| Cutting methods | Side discharge (optional bagger and mulch kit) |
| Cutting deck material | Steel |
| Deck thickness gauge | 11 |
| Anti-scalp wheels | 3 |
| Deck lifting system | Foot Operated, Spring Assisted |
| Blade engagement | PTO switch |
| Blades | 3 |
| Mower Cut Height (inches) | 5 |
| Mower Cut Height Min (inches) | 1.5 |
| Cut Height Increments count | 8 |
| Cutting height adjustment | Notch (Foot Operated) |
| Lift system | Foot Operated, Spring Assisted |
| Mower Deck Material | Welded steel |
| Mower Drive System | Belt |
| Mower Wheels | 4 |
| Spindle Bushings | Steel |
| Drive Details | |
| Steering type | Zero turn |
| Interlock system | |
| Drive system type | Hydrostatic |
| Wheel type | Pneumatic |
| Front Wheel Diameter | 12 x 6-6 inches |
| Rear Wheel Diameter | 20 x 10-10 inches |
| Front Axle material | Welded steel |
| Transmission Type | Hydrostatic |
| Transmission manufacturer | Hydro-Gear |
| Transmission control | Lever-operated |
| Transmission cooling | Fan-cooled |
| Other Specs & Features | |
| MSRP | $6,599.95 |
| Country of assembly | USA |
| UPC code | 728172399462 |
| 12 Volt Outlet | |
| Covered Toolbox | |
| Cupholder | |
| Hourmeter | |
| Chassis frame | Welded steel |
| Receiver Hitch | (front and rear) |
| Starter type | Key start (electric) |
| Fuel Tank Capacity | 8 gal. (Or 30.28L / 32 qts.) |
| Manufacture product ID | ZTR2766BS |
| AlphaMetrics | |
| Width (inches) | 76.5 |
| Height (inches) | 46 (with ROPS folded down) |
| Width (mm) | 1943.1 |
| Height (mm) | 1168.4 |
| General Specs | |
| Main category | Zero-turn lawn mower |
| Weight | 860lbs. |
| Warranty | 3 years |
Description:
With a 27hp motor powering a wider-than-average 66-inch cutting width, and with an 8-gallon fuel tank, the ZTR2766BS is comparable to a pro mower. A top speed of 8mph (for reverse too) and eight height adjustments ranging from 1.5 to 4.5 inches complement its features. Also noteworthy is the 11-gauge deck construction (which, by the way, is common to the 60-inch width category).
Also called Swisher 66-inch Briggs and Stratton.
