Full Innovair Quantum HP WIN12H2V51 A/C Specs (USA Version)
12000
BTU
cooling
14500
BTU
heating
26
db
Min. Noise
Our Score: 88%
| Release month | 12 |
| Release quarter | 04 |
| Basics | |
|---|---|
| Main category | Split air conditioner |
| SERIES | Quantum HP |
| Model Variants | WIN12H1V51 (115V variant) |
| Weight | 20lbs. (60 lbs for outdoor unit) |
| Height (inches) | 10.5 (19 inches for outdoor unit) |
| Width x Height | 32-inch wide x 10.5 (19 inches for outdoor unit)-inch high (28 inches for outdoor unit) |
| Depth | 8.5 inches (9.5 inches for outdoor unit) |
| Width (mm) | 812.8 |
| Height (mm) | 266.7 |
| Depth (mm) | 215.9 |
| Cooling system | Inverter technology with heat pump |
| Energy Efficiency | |
| Seasonal Energy efficiency ratio (SEER) | 16.7 |
| Heating seasonal performance factor (HSPF) | 9 |
| Refrigerant charge (oz) | 35.3 (up to 25-ft pre-charged and 0.22 oz additional charge per feet) |
| Functions | |
| Air deflection | ? (There is a vent-swing function) |
| Automatic setting |  (Auto Self-Clean) |
| On-off timer | ? -hour (There is a timer function) |
| Dehumidifier Specs | |
| Dehumidification (L/Hour) | 1.2 |
| Dehumidification (oz/Hour) | 40.58 |
| Dehumidification (Pints/Hour) | 0.1 |
| Lowest operation temperature (F) | 32 °F (-4F for heating) |
| Highest operation temperature (F) | 115 °F (75F for heating) |
| Defrost system | ? (They mention an anti-freeze feature) |
| Performance | |
| Cool BTU rating | 12000 BTU |
| Compressor features | Gold-Fin layer, 5.8 RLA |
| Heat BTU rating | 14500 (They mention a range of 2500 to 14500 BTU) |
| Estimated cool area | 450 Square feet. (Amazon mentions ranges of 450 to 650 sq. ft. and 650 to 900 sq. ft.) |
| Air flow | 500CFM (14.16 cubic metre/min.) |
| Amps | 5 (also 5A for heating) |
| Voltage | 230 (208 to 230V or 115V, at 60Hz) |
| Min. noise level | 26dBA |
| Max. noise level | 35dBA |
| Min. noise level (outdoors) | 54dBA |
| Convenience | |
| Remote control | (with LCD readout) |
| Auto restart | |
| Other Specs & Features | |
| Certifications | AHRI, ETL |
| Preset programs | Dehumidifier, Hyper Heat, Sleep Mode, Turbo Cool |
| Wi-Fi | (optional wireless controls) |
| Release year | 2018 |
| Filtration percentage | 90 % |
| Air filter details | Multi-layer (HEPA + vitamin C + catechin + aroma) |
| Refrigerant | R410A |
| Special Included Accessories | 16-feet installation kit, 5-meter copper line, Inter-connecting cable kit |
| Available colors | White |
| Display Type | Body-integrated White LED |
| Manufacture product ID | WIN12H2V51 (WIN12H1V51 for 115V variant) |
Description:
Also called Innovair WIN12H2V51, Innovair 12000 BTU Ductless AC with Heat, Innovair 12000 BTU Mini-Split Air Conditioner with Heat.
