Complete Perfect Aire 1PAMSHH12 A/C Specs
12000
BTU
cooling
11800
BTU
heating
24
db
Min. Noise
Are You Sure It Is Your Best Choice? Check These:
| Release month | 06 |
| Release quarter | 02 |
| Basics | |
|---|---|
| Main category | Split air conditioner |
| Number of zones | 1 |
| Weight | 19.84lbs. (88.2 lbs for outdoor unit) |
| Weight lbs with package | 26.68 (93.7 lbs for outdoor unit) |
| Height (inches) | 11 (21.81 inches for outdoor unit) |
| Width x Height | 32.81-inch wide x 11 (21.81 inches for outdoor unit)-inch high (31.5 inches for outdoor unit) |
| Depth | 7.81 inches (13.125 inches for outdoor unit) |
| Width (mm) | 833.4 |
| Height (mm) | 279.4 |
| Depth (mm) | 198.4 |
| Cooling system | Inverter (with HyperTek heat technology) |
| Energy Efficiency | |
| Energy efficiency ratio (EER) | 13 |
| Performance Certification | AHRI |
| Seasonal Energy efficiency ratio (SEER) | 22.5 |
| Heating seasonal performance factor (HSPF) | 12 (12 for HSPF4, 9.9 for HSPF5) |
| Refrigerant charge (oz) | 52.9 (with 25-feet pre-charge and 0.161-oz charge per additional feet) |
| Functions | |
| Air deflection | Auto |
| Security features | Refrigerant leakage detection |
| Dehumidifier Specs | |
| Dehumidification (L/Hour) | 31.2 |
| Dehumidification (oz/Hour) | 1056.00 |
| Dehumidification (Pints/Hour) | 2.75 |
| Lowest operation temperature (F) | -22 °F (for both cooling and heating) |
| Highest operation temperature (F) | 122 °F (86F for heating) |
| Performance | |
| Cool BTU rating | 12000 BTU |
| Compressor features | Hydrophilic aluminum fin |
| Heat BTU rating | 11800 |
| Cooling fan speeds | 3 (also 3 for heating) |
| Air fan speeds | 3 (Low, Medium, High) |
| Air flow | 418CFM (11.84 cubic metre/min.) (418 CFM on High, 324 CFM on Med, 247 CFM on Low) |
| Amps | 4.2 (4.24A for heating) |
| Voltage | 230 (208 to 230V, 60Hz, 1 Phase) |
| Min. noise level | 24dBA |
| Max. noise level | 43dBA (43dBA on High, 36dBA on Med, 24dBA on Low) |
| Convenience | |
| Remote control |  (with Follow Me thermostat function) |
| Air discharge type | 360-degree air flow panel |
| Other Specs & Features | |
| Certifications | Energy Star, ETL |
| Health advisory | Prop 65 |
| Preset programs | Turbo, Sleep |
| Release year | 2020 |
| Air filter details | Silver Ion |
| Refrigerant | R410A |
| Special Included Accessories | 16AWGx4 stranded and unshielded wiring |
| Available colors | White |
| Display Type | Blue LED |
| Manufacture product ID | 1PAMSHH12-SZW-22.5 (1PAMSHH12-SZO-22.5 for outdoor unit) |
Description:
Also known as Perfect Aire 12000 BTU HyperTek Heat Mini-Split AC, Perfect Aire 12000 BTU Ductless Air Conditioner with Heat.
