Complete Perfect Aire 3PATWH10002 A/C Specs (USA Version)
10000
BTU
cooling
10600
BTU
heating
53
db
Min. Noise
Our Score: 66%
| Release month | 07 |
| Release quarter | 03 |
| Basics | |
|---|---|
| Main category | Wall air conditioner |
| Weight | 69lbs. |
| Weight lbs with package | 80 |
| Height (inches) | 14.5 |
| Width x Height | 24.5-inch wide x 14.5-inch of height |
| Depth | 20.5 inches |
| Width (mm) | 622.3 |
| Height (mm) | 368.3 |
| Depth (mm) | 520.7 |
| Cooling system | Compressor with electric heater |
| Warranty | 1 year |
| Energy Efficiency | |
| ENERGY STAR annual cost | 94 |
| Energy efficiency ratio (EER) | 9.6 |
| Electric safety certification | CUL (US) |
| Energy saver |  |
| Functions | |
| On-off timer | 24 -hour |
| Performance | |
| Cool BTU rating | 10000 BTU (They mention 10000/9800 BTU) |
| Heat BTU rating | 10600 (They mention 10600/8600 BTU) |
| Maximum temperature (C) | 30 |
| Minimum temperature (C) | 17 |
| Estimated cool area | 400 Square feet. (400 to 450 sq. ft.) |
| Cooling fan speeds | 3 (1 speed for heating) |
| Air fan speeds | 3 |
| Minimum temperature | 62 °F (17°C) |
| Maximum temperature | 86 °F (30°C) |
| Amps | 5 (They mention 4.6/5A for cooling and 15/13.5A for heating) |
| Voltage | 230 (20 AMP outlet) |
| Watts | 1042 W (They mention 1042/1021W for cooling and 3450/2821W for heating) |
| Min. noise level | 53dB |
| Max. noise level | 57dB (57dB on High, 55dB on Med, 53dB on Low) |
| Convenience | |
| Remote control | (with Follow Me portable thermostat technology) |
| Control Location | Front |
| Auto restart | |
| Other Specs & Features | |
| Button type | Electronic control panel |
| Certifications | Prop 65 |
| Indicator lights | (Check Filter light) |
| Optional Accessories | Standard wall sleeves |
| Preset programs | Auto, Cool, Dry, Energy Saver, Heat, Sleep |
| Release year | 2018 |
| Air filter details | Slide-out access |
| Refrigerant | R410A |
| Special Included Accessories | Interior trim kit |
| Available colors | White |
| Display Type | Green LED |
| Manufacture product ID | 3PATWH10002 |
| UPC code | 842149024178 |
Description:
Also known as Perfect Aire 10000 BTU Through-the-Wall Air Conditioner with Heat.
